Romero Long Travel - XO

Frameset Technical Specifications //

Please note: Based on component availability, specifications are subject to change without notice.

FRAME //

Material // Velospec Air-Hardened Steel Front Triangle with 316L 3D-Printed Steel Inserts

Swingarm Material // 6061 Aluminum (Hand-Fabricated) with 7075 Aluminum Hardware

Finish // Durable Powder Coat

Dropouts // Interchangeable UDH-Compatible; 29" and 27.5" Options; 435mm and 445mm Chainstay Lengths

Drivetrain Compatibility // 1x Mechanical and Electronic; Full-Length Housing; 55mm Chainline

MAX Tire Clearance // 29 x 2.6" (~750mm OD); 29" or 29/27.5" Mullet Configuration

MAX Chainring // Up to 38t Oval; 55mm Chainline

Dropout Spacing // Boost 148 x 12mm

Rear Axle // 180mm - M12 x 1.0 (UDH Threading)

Brake Mount // 180mm Direct Mount; Up to 220mm Rotor

Cable Routing // External Brake and Derailleur with Bolt-On Zip-Tie Guides

Dropper Routing // External with Bolt-On Guides, Internal Port at Seat Tube

Seatpost Diameter // 31.6mm

Seatpost Clamp Diameter // 34.9mm

Bottom Bracket // T47 External (73mm Shell)

Headtube Diameter // 44mm Internal Top and Bottom

Headset Specs // Upper: ZS44/28.6 - Lower: EC44/40

Mounts // Bottle Mount Inside Front Triangle; Accessory Mount Under Top Tube at Seat Tube

SUSPENSION //

Rear Travel // 150mm (60mm stroke) to 160mm (65mm stroke)

Rear Shock // Trunnion Mount, 205mm x 65mm

Fork Travel // 170mm

Fork Axle-to-Crown // 583.7mm

Fork Rake // 44mm

Sizes // M, M/L, L, XL, XXL

Intended Use // Enduro / Long-Travel Trail

SRAM XO Eagle Transmission Build Kit Details //

Please note: Based on component availability, specifications are subject to change without notice.

DRIVETRAIN //

Groupset // SRAM XO Eagle Transmission w/ 165mm Cranks

BRAKES //

Brakes // SRAM Maven Silver

Rotors // SRAM HS2 — 200mm F / 180mm R

COCKPIT //

Stem // Race Face Turbine R 35mm — 40mm length

Handlebar // Race Face Era Riser Bar — 35mm clamp, 780mm width, 20mm rise

Grips // Race Face Getta Grip 33mm — Black

Dropper Post // Fox Transfer Performance Elite

Dropper Remote // FOX Transfer Post Lever — 1x

Seatpost Collar // Alloy — Black

Saddle // WTB Silverado

Pedals // Not Included

TIRES //

Front Tire // Maxxis Assegai 29 x 2.5

Rear Tire // Maxxis Dissector 29 x 2.4

Suspension Options — Long Travel //

Choose from three suspension packages at checkout.

MARZOCCHI PACKAGE //

Fork // Marzocchi Bomber Z1

Shock // Marzocchi Bomber Air

FOX FACTORY PACKAGE //

Fork // Fox Factory 38 Grip X2

Shock // Fox Factory Float X2

ROCKSHOX PACKAGE //

Fork // RockShox Zeb Ultimate

Shock // RockShox Super Deluxe Ultimate

Wheelset Options //

Choose your wheelset at checkout.

ALLOY //

Wheelset // DT Swiss M1900 Spline 29

CARBON //

Wheelset // Stoic Wheelset — Stoic Rims laced to DT Swiss 350 Hubset

With a Complete //

All parts listed under the complete build kit specifications will be fully installed, tuned, and ready to ride*

*Some assembly will be required out of the box

Wheels // Will ship setup tubeless with sealant installed

Charger // SRAM AXS single battery charger

Documentation // Welcome to the Stinner Family

With a Frame //

Headset // Not Included - CLICK HERE for compatible headset options

Hanger // SRAM UDH

Rear Axle // Stinner Select UDH - 180mm x M12 x 1.0

Bottle Boss Bolts // QTY. 7 Stainless Bolts

Chainstay Protector // Clear Vinyl - Installed

Bolt-On Guides // QTY. 4 Stinner Select Cable guides - Triple

Zip Ties // QTY. 5 Small Zip Ties - Black

Seat Post Clamp // Stinner Select 34.9mm

Documentation // Welcome to the Stinner Family

NOTE // Frame saver will need to be applied to the inside of the frame before it is built up.
